DB25 Male Solderless Breakout Connector with 5Ft 26AWG Replacement Cable, Plastic Shell RS232 D-SUB Serial to 25-Pin Port Terminal Male Adapter Connector Breakout Board

The DB25 solderless breakout connector is a connector that can be attached to a DB25 interface without the need for soldering. It provides easy access to the individual pins, making it easier to connect wires or other components. It also comes with a 5-foot-long replacement cable that uses 26-gauge wire. Technical Specifications: Name: DB25 solderless module with cable Plug type: male Connector material: pure copper plated joint Terminal Material: red copper Housing material: plastic shell Cable Length: 1.5m/5Ft Cable Specification: 26AWG Thickness: 16mm/0.63″ Application: tax control machine, digital camera, PLC, PDA, MODEM, set-top box, barcode machine, industrial instrumentation, etc. Size: 57 mm×56 mm×16 mm/ 2.24″×2.20″×0.63″ Package includes: 1 x DB25 Male Solderless Connectors with 1.5m Bare Wire End Cable

• DURABLE: Pure copper plated joints, fine solder joints, resistance to plug, and good contact to ensure high-quality, durability and a long life.
• Stable Transmission: This DB25 Solderless Breakout Connector adopts 26AWG double-layer shielded cable and copper crimp terminals, which has stable signal transmission and good shielding effect.
• DB25 line sequence color comparison table: 1. Black; 2. Brown; 3. Brown and white; 4. Red; 5. Red and white; 6. Red and black; 7. Orange; 8. Orange and black; 9. Yellow; 10. Yellow and white; 11. Yellow and black; 12. Green; 13. Green and black; 14. Blue; 15. Blue and black; 16. Purple; 17. Purple and black; 18. Grey; 19. Grey and black; 20. White; 21. White and black; 22. Pink; 23. Pink and black; 24. Light green; 25. Light green and black.
• The cable length is 1.5m/5Ft, the compact and simple design is easy to carry and place, easy to use and resistant to bending and stretching.
• WIDELY APPLICATIONS: It can connect all kinds of rs232/rs485 and other communication protocols devices. Such as computer and tax control machine, digital camera, PLC, PDA, MODEM, set-top box, barcode machine, industrial instrumentation and other equipment for communication.
